1. Main technical specifications
The values below use published RK6180 manufacturer specifications as a reference, including a flat-bed model with an 800 mm swing over bed.
| Specification | Unit | RK6180×1000 | RK6180×1500 | RK6180×2000 | RK6180×3000 |
|---|---|---|---|---|---|
| Distance between centers | mm | 1000 | 1500 | 2000 | 3000 |
| Max. swing over bed | mm | 800 | 800 | 800 | 800 |
| Max. swing over cross slide | mm | 560 | 560 | 560 | 560 |
| Approx. maximum turning length | mm | 850–950 | 1350–1450 | 1850–1950 | 2850–2950 |
| Spindle bore | mm | 86/105 | 86/105 | 86/105 | 86/105 |
| Spindle motor power | kW | 11–15 | 11–15 | 11–15 | 11–15 |
| Component | Recommended specification to confirm |
|---|---|
| CNC system | GSK, FANUC, Siemens or equivalent |
| Tool turret | 4-station electric; 6- or 8-station options may be available |
| Chuck | Ø400 mm on suitable versions; verify compatibility |
| Tailstock | Manual or hydraulic |
| Steady rest | Fixed or travelling, selected for workpiece diameter |
| Follow rest | Optional for slender shafts |
| Chip removal | Coolant tray standard; chip conveyor optional |
| Lubrication | Automatic centralized lubrication |
| Electrical supply | Confirm local voltage, frequency and phase |
| Safety | Chuck guard, emergency stop, interlocks and applicable certification |
What to confirm before buying
-
Maximum swing over bed and cross slide.
-
Actual cutting length for each center-distance option.
-
Spindle bore and maximum bar capacity.
-
Spindle motor power and torque at low speed.
-
X/Z travel, rapid traverse and positioning accuracy.
-
Chuck, turret, tailstock and steady-rest inclusions.
